5. Press the [Menu] key.

BMW028S

6. Press the [ ] or [ ] key to select [Paper Input], and then press the [OK] key.

7. Press the [ ] or [ ] key to select [Paper Size: Bypass Tray], and then press the [OK] key.

8. Select the paper size you want to set using the scroll keys, and then press the [OK] key.

5. Paper and Other Media

130
