4. Turn lever R2 counterclockwise.

BEK068S

5. Open the left cover of the bridge unit and remove the paper.

BEK069S

6. If the paper cannot be removed, open lever R3 and remove the paper.

BEK070S

Paper Misfeed Message (R)

249
