Push it firmly into the printer using the handle. The printer may malfunction if the controller board is
not properly installed.
13. Fasten the controller board to the printer using the five screws.
When you turn the power to the printer on, the hard disk will be formatted automatically.
• Confirm that the hard disk was correctly installed by printing the configuration page. If it is correctly
installed, "Hard Disk Drive" will appear for "Device Connection" on the configuration page.
• If the hard disk was not installed properly, repeat the procedure from the beginning. If it cannot be
installed correctly even after reattempting installation, contact your sales or service representative.
• For information on printing the configuration page, see "List/Test Print Menu", Software Guide.
• Install the controller board carefully. For details, see "Cautions When Re-installing the Controller
Board".
• To use the installed hard disk, configure the printer options in "Change Accessories" in the printer
driver. For information about opening "Change Accessories", see "Making printer default settings -
the printer properties", Software Guide.
• p.35 "Cautions When Re-installing the Controller Board"
Installing the Memory Expansion Units
53
