Ricoh Aficio SP C820DN

To Next Page

To Previous Page

2. Turn the printer off and unplug the power cable.

3. Loosen the two screws and remove the slot cover.

BMV165S

The removed cover will not be reused.

4. Fully insert the interface unit.

BMV174S

Confirm that the interface unit is firmly connected to the controller board.

5. Tighten the two screws to secure the interface unit.

BMV175S

Installing the Interface Units
