Ricoh Aficio SP C820DN

6. Attach the card to the card adapter. Attach them so that the label on both the card and
adapter is facing up.
BFL316S
7. With the label side facing left, slowly push the card adapter into the interface unit until it
stops.
BMV176S
8. While holding the cover close to the tabs, align the three tabs on the cover with the three
indentations on the interface board, and then attach the cover.
BMV285S
• Confirm that the Bluetooth interface unit was correctly installed by printing the configuration page. If
it is correctly installed, "Bluetooth" will appear for "Device Connection" on the configuration page.
2. Installing Options
64
2
