INPUT/OUTPUT CHECK
SM 5-173 B064 Series/B140 Series/G126
Service
Tables
Reading
Class 3
No.
Bit
No.
Description
0 1
7 Not Used
6 Not Used
5 Not Used
4 Not Used
3 Emergency Stop Switch Not press Press
2
Shift Jogger Lift HP Sensor
(Optional Jogger Unit)
Home position Not home position
1
Shift Jogger HP Sensor
(Optional Jogger Unit)
Not home position Home position
6
0 Optional Jogger Unit Connection Connection Not connection
