Ricoh B064 - Z-Fold Jogger Unit (B674 Only)

Z-FOLD JOGGER UNIT (B674 ONLY)
B468/B469/B674 10 SM
1.10 Z-FOLD JOGGER UNIT (B674 ONLY)
1. Open the front door and pull out the stapler tray unit.
2. Remove the Z-fold jogger unit cover [A]. ( x 2)
3. Remove the Z-fold jogger unit cover [B]. ( x 1)
4. Remove the Z-fold jogger unit [C] ( x 4,  x 4,  x 2)
B468R900.WMF
[A]
[B]
[C]
