9.2.2 Tray 1, Tray 2
CAUTION
• Make sure that the main machine is switched off and that its power cord is
disconnected before doing the following procedures.
1
6
2
7
3
8
4
9
5
10
CEZ227
Tray 1 Tray 2
1 1st pickup roller 6 2nd pickup roller
2 1st paper feed roller 7 2nd paper feed roller
3 1st separation roller 8 2nd separation roller
4 1st paper feed sensor 9 2nd paper feed sensor
5 1st grip rollers 10 2nd grip rollers
