Ricoh D074 Series Replacement Guide

43
4. Remove the black screw on the sensor positioning plate.
CEZ171
5. Push the sensor positioning plate to the left.
Note: If this plate is not pushed to the left, you will not be able to remove the
paper feed roller.
6. Remove the paper feed roller in the following order:
(1) Pick-up roller snap ring and roller
(2) Feed roller snap ring and roller
(3) Separation snap ring and roller
3
1
2
CEZ172
