Ricoh D074 Series Replacement Guide

49
8. Push the lever to the rear (1) to release it, and then pull up the lever (2).
1
2
CEZ111
9. Holding the ends of the charge roller unit where the purple labels are, lift the
end of the unit facing the front of the machine and remove the unit.
CEZ112
10. Hold the drum handle at both ends and pull it up.
CEZ130
