Page #178 background imageLoading...
Page #178 background image
Engine SP Mode
SM 5-34 D245/D246/D247
5183 [Refeed start adj.]
Adjusts the feed timing of the pape feed clutch in the optional PFU 1 for the
next job.
5-183-002
Bank1 *ENG [-10 to 10/ 0 / 1 mm / step]
5183 [Re-feed timing]
Adjusts the feed timing of the pape feed clutch in the optional PFU 2 for the
next job.
5-183-003
Bank2 *ENG [-10 to 10/ 0 / 1 mm / step]
5801 [Memory Clear]
5-801-002 Engin ENG [- / - / -]
[Execute]
Initializes all registration settings for the engine and copy process settings.
5803 [Input Check]
See "page 5-42 "Input Check"".
5804 [Output Check]
See "page 5-44 "Output Check"".
5810 [SC Reset]
Resets a type A service call condition.
ï‚§ Turn the main switch off and on after resetting the SC code.
5-810-001
Fusing SC Reset ENG [- / - / -]
[Execute]
