Ricoh MP 2014D - DF Model Installation

Copier Installation
SM 2-5 D245/D246/D247
Installation
2.2.2 INSTALLATION PROCEDURE
 Unplug the machine power cord before starting the following procedure.
1. Remove filament tape and other padding.
DF Model (D247)
Platen Model (D245/D246)
2. Open the ADF [A] or platen cover [B], and then remove the sheet and filament tapes.
Rev. 01/22/2016
