1. Check the contents of the package.
321
EAG373
1. Hard disk
2. Flat cable
3. Power cord
2. Remove the HDD cover.
EAG355
3. Loosen the screws by using a coin, and then slide the inner cover to the top to remove it.
1
1
2
EAG356
The figure below shows the location to attach the hard disk drive. It also shows the locations of the
receptacles to plug the power cord and the SATA flat cable.
Installing Options
25
