3
2
1
EAG357
1. Power cord receptacle
2. SATA flat cable receptacle
3. Location to attach the hard disk drive
4. Connect the flat cable and power cord to the hard disk.
5. Lock the hard disk drive on the printer using two screws.
EAG374
6. Plug the power cord into the power cord receptacle with the claw on the cord facing
upward.
EAG375
1. Getting Started
26
