7. Insert the SATA flat cable into the SATA flat cable receptacle with the claw on the cable
facing upward.
EAG376
• Connect the SATA flat cable in a way so that the cable goes around the power cord from
below.
• Do not twist the SATA flat cable.
8. Insert the five protrusions on the provided inner cover into the notches on the printer.
EAG360
9. Tighten the screw.
EAG361
Installing Options
27
