Ricoh Printer/Scanner Unit Type 8000 - Page 121

Items for Specifying Scan Settings
113
6
C Press [Custom Size].
D Specify Original Size (X1 and Y1) using the number keys, and then press
the {q} key.
For example, set X1 to 300 mm and Y1 to 200 mm.
E Set Start Position (X2 and Y2) to 0 mm, and then press the {q} key.
For example, set X2 and Y2 to 0 mm, and press the {q} key.
F Specify Scan Area (X3 and Y3) using the number keys, and then press the
{q} key.
For example, set X3 to 300 mm and Y3 to 200 mm.
G Press [OK].
H Check Scan Area (X3 and Y3) displayed above [Custom Size], and then press
[OK].
