Ricoh SP 230DNw User Manual

2-63
Confidential
4.6 Troubleshooting for Control Panel Problems
4.6.1 Nothing is displayed on the LCD
<User Check>
• Turn the power switch OFF and then back ON again.
• Unplug the AC cord and then plug it again.
4.6.2 Unable to perform panel operation
<User Check>
• Turn the power switch OFF and then back ON again.
4.7 Troubleshooting for Toner Cartridge and Drum Unit
Problems
4.7.1 New toner not detected
<User Check>
• Be sure to set a new toner cartridge.
Step Cause Remedy
1
Connection failure of the
panel relay flat cable
Reconnect the panel relay flat cable.
2
Connection failure of the low-
voltage power supply PCB
harness
Reconnect the low-voltage power supply
PCB harness.
3 AC cord failure Replace the AC cord.
4
Connection failure of the LCD
relay flat cable
Reconnect the LCD relay flat cable.
5 Panel relay PCB failure Replace the panel relay PCB ASSY.
6 LCD failure Replace the LCD panel ASSY.
7
Low-voltage power supply
PCB failure
Replace the low-voltage power supply PCB
ASSY.
8 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Connection failure of the low-
voltage power supply PCB
harness
Reconnect the low-voltage power supply
PCB harness.
2
Connection failure of the LCD flat
cable
Reconnect the LCD flat cable.
3
Connection failure of the panel
flat cable
Reconnect the panel flat cable.
4 Panel PCB failure Replace the panel PCB ASSY.
5
Low-voltage power supply PCB
failure
Replace the low-voltage power supply
PCB ASSY.
6 Main PCB failure Replace the main PCB ASSY.

Ricoh SP 230DNw Specifications

General

Color	No
Print technology	-
Maximum resolution	600 x 2400 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	64 MB
Maximum internal memory	- MB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	- W
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	GDI
Average cartridge yield (black)	1200 pages
Cartridge(s) included	Yes
Included cartridge capacity (black)	700 pages
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B4
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	White
Market positioning	Home & office
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1

Weight and Dimensions

Depth	360 mm
Width	356 mm
Height	183 mm
Weight	7300 g
