Ricoh SP 4510 DN

Guide to Names and Functions of Components
Guide to Components
• Do not obstruct the machine's vents. Doing so risks fire caused by overheated internal
components.
Exterior: Front view
2 31
4
5
6
7
8
15
14
13
12
11
9
10
CYN001
1. Front cover
Open to access the inside of the printer and remove jammed paper.
Open here to replace the print cartridge and the drum unit.
