DSE259
Paper feed roller
Wipe around the paper feed roller by turning it with a damp cloth. Then, wipe it with a dry
cloth to remove any water.
DUP349
After that, wipe it with a dry cloth to remove the water.
6. Load the removed paper stack in the tray.
7. Lift the front side of the tray, and then slide it into the printer carefully until it stops.
DUP203
Do not slide the paper tray in forcefully. Otherwise, the front and side guides might move.
8. Firmly insert the plug of the power cord into the wall socket. Connect all the interface
cables that were removed.
9. Turn the main power switch on.
Cleaning the Printer
59
