24. Release and pull down duplex transport path plate (Z3).
DFP339
25. Turn the knob Z1.
DFP341
26. Clean the rollers (as you rotate the knob) and sensors.
1
2
3
5
7
8
11
4
6
9
10
DFP340
8. Troubleshooting Paper Delivery Problems
112
