Page #65 background imageLoading...
Page #65 background image
Check Point Comment
Options
Return all options (PFU, Bypass Tray, NIC, etc.) to customer.
Note: Network settings are stored on the NIB. If the NIB is not swapped, the
settings do not need to be done again after machine swapping.
What You Need
The following items and equipment are required for packing the machine before shipping.
Boxes
Vinyl Bag
InstaPak Kit or InstaPak Quick Kit
Ink Cartridges
Model Name Production Name Ink Cartridges Needed
GX3000/GX3050 Toscana P1 C, M, Y, K: Medium-Size Cartridges
GX5050 Piemonte P1
C, K: Medium-Size Cartridges
M, Y: Large-Size Cartridges
The large M, Y cartridges are required for the Piemonte P1 because the amount of ink required
at initial refilling is larger. For more details, please refer to "Print Head" in Section "6. Details" of
the Service Manual.
Vinyl Bag Specifications
Material Width Length Thickness
Low-density Poly-ethylene 1200 mm (47.4") 800 mm (31.5") 0.07 mm (0.003")
This bag can be used to wrap either the Toscana-P1 or Piemonte-P1.
6. 6. Preparing a Machine for Transport
64
6
