2.Replacement and Adjustment
24
5. Remove the handle [A], which is attached to the frame of the trimmer unit.
6. Open the feed unit [A].
7. Remove the screws on the guard plate [A] ( x2).
• The guard plate is permanently attached to the blade; it will not come off even if the
screws are removed.
