TABLE 1-1: LIFT COMPONENTS FOR DEDICATED ENTRY MODEL
REF NAME DESCRIPTION
Left, Right, Front, Rear
Reference points from outside vehicle looking inward at lift.
1 Pump Enclosure Contains lift electrical and hydraulic control components.
2 Electric Circuit Breakers Prevent over-current damage to lift electrical components.
3 Hydraulic Pump Assy. Electro-hydraulic unit provides hydraulic pressure that raises platform.
4 Pump Handle Used to manually operate hydraulic pump, or to release platform.
5 Pull Box Houses electrical termination points to lift, and a hydraulic line disconnect point.
6 Control Pendant Hand-held device used to control lift operation.
7 Carriage
Part of traveling frame that is mounted on rollers; moves on rails located inside
enclosure. Supports lifting frame.
8 Deployment System Part of carriage. Employs an electric gear-motor to propel platform out of enclo-
sure, or pull it back in.
9
Manual Platform Re-
lease Shafts
(2ea.)
Used when electric power is not available to lift. Releases platform from enclo-
sure to facilitate manual deployment. Actuated by engaging and rotating
either shaft.
10 Slam-Lock Handle
Locks handrail in upright position. L-handle unlocks handrail from upright position
before lowering.
11 Lifting Frame
Hinged arms that lift or lower platform; driven by single hydraulic cylinder
attached to carriage.
12
Manual Rollstop Control
Knob
Provides manual control of rollstop if electrical power is lost.
13 Platform Rollstop
Front barrier prevents wheelchair from inadvertently rolling off the platform during
lift use.
14 Platform Curbed-in area occupied by passenger during lift operations.
15 Occupant Safety Belt Safety belt helps prevent unintentional acceleration of wheelchair from platform.
Electrically interlocked; “UP” and “DOWN” functions are disabled when belt is
unbuckled.
16 Standee Handrails Provides platform occupant with a stable handhold.
17 Bridgeplate Plate unfolds at floor height; bridges gap between rear of platform and floor.
18 Enclosure Platform and carriage housing; rigidly attached to vehicle chassis.
19 Controller Converts pendant commands to control signals for electrical components. Moni-
tors lift operation.
END OF TABLE
