IV. F9T MAJOR COMPONENT SERVICE
his chapter provides instructions for major system repairs, system adjustments, and parts replacement on the
RICON Mirage F9T Series Transit Use Wheelchair and Standee Lift.
Maintain the lift at its highest level of performance by doing the required maintenance. Ricon recommends
a thorough inspection every six months.
Nearly all illustrations in this chapter apply to both Dedicated Entry and Stepwell models. As a result,
some illustrations may differ slightly from what is being worked on.
A specific repair task might not require completion of all listed steps in a procedure.
Additional component illustrations are available in the Spare Parts chapter.
A. GENERAL SAFETY PRECAUTIONS
WARNING!
THIS RICON PRODUCT IS HIGHLY SPECIALIZED. AN AUTHORIZED RICON SERVICE
TECHNICIAN MUST PERFORM MAINTENANCE AND REPAIRS USING RICON REPLACE-
MENT PARTS. MODIFYING OR NOT PROPERLY MAINTAINING THIS PRODUCT WILL
VOID THE WARRANTY, AND MAY RESULT IN UNSAFE OPERATING CONDITIONS.
The following general safety precautions must be followed during service and maintenance:
Do not attempt maintenance, repairs, or adjustments without the presence of a person capable of
rendering first-aid.
Take notice of all injuries, regardless of how slight. Administer first aid or seek medical attention im-
mediately.
Wear protective eye shields and appropriate clothing at all times.
Work in a properly ventilated area. Do not smoke, or use an open flame, near the battery.
Exercise caution when operating lift to avoid injury. Be certain that hands, feet, legs and clothing are
not in path of the platform as it moves.
Be cautious when using metallic (conductive) tools near the battery, or heavy gauge wires.
If battery acid contacts skin, wash area immediately with soap and water.
Check under vehicle before drilling or cutting to avoid damage to the frame, subframe members, wir-
ing, hydraulic lines, etc.
Thoroughly understand the operating instructions before attempting to operate lift.
Keep others clear during lift operation.
