Ricon Mirage F9T User Manual

32DF9T02.C
5 - 5
FIGURE 5-3: F9T PUMP BOX ASSEMBLY
REF ITEM DESCRIPTION QTY/ASSY PART NO.
1A PUMP ENCLOSURE W/COVER , (F9T-DE001) 1 19555
1B* PUMP ENCLOSURE ASSY, (F9T-DE002, F9T-DE021, F9T-DE025, 1 F9-0371
F9T-DE026, F9T-SG004, F9T-SG005)
2A MANUAL BACK-UP PUMP HANDLE 1 20122
2B MANUAL BACK-UP PUMP HANDLE, ANGLED 1 20130
3 KIT, PUMP BOX LOCK, W/ BLOCK 1 19556
4A PUMP ASSY, 2KPSI, 24V, (F9T-DE001) 1 PM224002007
4B PUMP ASSY, 2KPSI, 24V, (F9T-DE002, F9T-DE021, F9T-DE025, 1 PM224003007
F9T-DE026, F9T-DE003)
4C PUMP ASSY, 2KPSI, 24V, (F9T-DE004) 1 PM224162007
4D PUMP ASSY, 2KPSI, 12V, (F9T-SG001, F9T-SG002, F9T-SG004, 1 PM212003007
F9T-SG005, F9T-DS001)
5 KIT, TOOL CLIP, PUMP HANDLE, (F9T-SG001, F9T-SG003) 2 19557
KIT, TOOL CLIP, PUMP HANDLE, (F9T-DE003, F9T-DS002, F9T-DS003) 1 01267
6A KIT, SOLENOID 24V, DOUBLE POLE, W/ HARDWARE 1 20669
6B KIT, SOLENOID 12V, DOUBLE POLE, W/ HARDWARE 1 20670
7A HOSE ASSY, HYD, 11”X1/4JICX1/4JIC, (F9T-DE001, F9T-DE002, F9T-DE003 1 F9-0333
F9T-DE021, F9T-DE025, F9T-DE026, F9T-SG001, F9T-DS001)
7B HOSE ASSY, HYD, 23’ SYNFLEX, (F9T-SG004, F9T-SG005) 1 F9-HH-23
7C HOSE ASSY, HYD, 13.75”, (F9T-DE004) 1 28883
8 RESERVIOR, HYDRAULIC POWER UNIT, PLASTIC 1 30938
9 BACK-UP PUMP ASSY, MANUAL W/O HANDLE 1 V2-SH-210
10 SEAL KIT, MANUAL BACK-UP PUMP 1 V2-SH-220
11A DOWN VALVE ASSY, 12V, DELTROL 1 V2-SH-105
11B DOWN VALVE ASSY, 24V, DELTROL 1 V2-SH-136
12 PLUG, BREATHER, RESERVOIR 1 10333
13A KIT, SOLENOID, 24V, SINGLE POLE, W/ HARDWARE 1 20667
13B KIT, SOLENOID, 12V, SINGLE POLE, W/ HARDWARE 1 20668
14 CIRCUIT BREAKER, 30A 1 26510
15 CIRCUIT BREAKER, 8A 1 265108
KIT, CIRCUIT BREAKER, 50 AMP 1 01291
16 KIT, TERMINAL STRIP, ELECTRICAL 1 20666
17 WASHER, RUBBER, 1”OD X 5/8”ID X 1/8” THICK 1 21602
18A KIT, SOLENOID PLATE ASSY, DE W/HDWR (F9T-DE001, F9T-DE004) 1 19559
18B SOLENOID PLATE ASSY, 24VDC (F9T-DE002, F9T-DE003, F9T-DE021 1 F9-0370
F9T-DE025, F9T-DE026)
18C KIT, SOLENOID PLATE ASSY, SW W/HDWR (F9T-SG001, F9T-SG002 1 20632
F9T-SG004, F9T-SG005, F9T-DS001)
19 CAP, FITTING, 1/4J, STL 1 V2-SH-13
20 FITTING, BUN, 1/4J, 2.08L 1 V2-SH-981
21 PUMP MOUNT BRACKET 1 F9-0204
22 PUMP MOUNTIMG BRACKET 1 17928
23 PUMP STIFFNER BRACKET 1 17929
* not shown
