Ricon Mirage F9T User Manual

32DF9T02.C
5 - 7
FIGURE 5-4: F9T LIFTING FRAME ASSEMBLY
REF ITEM DESCRIPTION QTY/ASSY PART NO.
1A KIT, LOWER ARM, DE 2 19596
1B KIT, LOWER ARM, SW 2 20630
2 Deleted
3 KIT, COVER, LOWER ARM 2 19598
4 KIT, PLATE, BRIDGEPLATE ACTUATOR 2 19599
5 Deleted
6 KIT, BEARING, DU, .75ID 1 20600
7A KIT, TRUNNION ASSY, SW 1 20601
7B KIT, RETROFIT, CLEVIS REINFORCEMENT, DE 1 19873
