32DF9T02.C
5 - 9
FIGURE 5-10: F9T ENCLOSURE ASSEMBLY
REF ITEM DESCRIPTION QTY/ASSY PART NO.
1 KIT, PULLBOX COVER, W/DECAL 1 19562
2 KIT, PULLBOX, ASSY 1 30945
3 KIT, HOSE CLAMP 1 19564
4 WEATHER STRIP, 1/8x1/2x100 FEET 1 06-06-107
5 SERVICE ACCESS PANEL 1 19565
6 KIT, ENCLOSURE COVER, 6.66” W/HDWR 2 19570
7 KIT, ENCLOSURE COVER, 19.98” W/HDWR 4 19566
8 KIT, ENCLOSURE COVER, 6.6” W/HDWR 1 19571
9 RAIL, CARRIAGE GUIDE 1 F9-0142
10 KIT, STOP BLOCK 2 19567
11 KIT, BLOCK-OFF PLATE 1 19568
12 KIT, ENCLOSURE COVER, 19.98” W/HDWR 1 19569
13A KIT, PLATFORM RELEASE SHAFT, DE 2 20639
13B KIT, PLATFORM RELEASE SHAFT, SW 2 20640
14A HARNESS, PUMP TO PULLBOX, 12FT (F9T-DE001, F9T-DE002, F9T-SG001) 1 18070
14B HARNESS, PUMP TO PULLBOX, 6FT (F9T-DE021, F9T-DE025, F9T-DE026) 1 F9-EHR-06
14C HARNESS, PUMP TO PULLBOX, 23FT (F9T-SG002, F9T-SG004, F9T-DS001) 1 19993
14D HARNESS, PUMP TO PULLBOX, 12FT (F9T-SG005) F9-EHR-12
15 HYDRAULIC HOSE ASSY, SYNFLEX, 12’ 1 F9-HH-12
16A HARNESS, PULLBOX TO STO-LOCK, LEFT 1 F9-0229
16B HARNESS, PULLBOX TO STOWLOCK, RIGHT 1 F9-0341
17 KIT, STO-LOCK, W/HDWR, SW 1 20671
KIT, STOW LOCK, W/SHIMS, REAR MOUNT 1 19933
18 HARNESS, ADAPTER, PULLBOX TO STO-LOCK 1 20106
19 SOLENOID, STO-LOCK 12V 1 F9-0339
20 GEAR RACK 2 F9-0028
21 BRACKET, BRIDGEPLATE GUIDE 1 19687
