Ricon Mirage F9T User Manual

32DF9T02.C
5 - 11
FIGURE 5-6: F9T PLATFORM ASSEMBLYDEDICATED ENTRY
REF ITEM DESCRIPTION QTY/ASSY PART NO.
1 KIT, SAFETY BELT RETRACTOR w/HDWR 1 22247
2 KIT, FOLDING HANDRAIL, LH 1 20618
3 KIT, HANDRAIL PIVOT BRKT ASSY, RH 2 20619
4 KIT, HANDRAIL PIVOT BRKT ASSY, LH 2 20620
5 KIT, HANDRAIL STRIKER 2 20621
6 SAFETREAD, 25.5 X 12, GRAY 2 25661
7 SAFETREAD, 12.75 X 3.0, YELLOW 1 25673
8 SAFETREAD, 5.5 X 1.5, YELLOW 4 25674
9 PLATFORM STIFFENER, FRONT 2 20622
10 KIT, ROLLSTOP ASSY 1 22238
11 KIT, PLATFORM GUIDE, RH 1 20624
12 KIT, STOW GUIDE BLOCK 2 20625
13 BEARING, DU, FLNG, ¾ ID X ¼ L, BAG OF 10 1 19576
14 SAFETREAD, 25.5 X 3, YELLOW 2 25664
15 KIT, PLATFORM STIFFENER, REAR 1 20626
16 KIT, LATCH ASSY 2 20627
17 KIT, FOLDING HANDRAIL, RH 1 20628
17-1 BUMPER, RUBBER, 1.00ODX.13THK (KIT OF 10) 2 20653
17-2 BUMPER, RUBBER, 1.00ODX.50THK (KIT OF 10) 2 30912
17-3 BUMPER, RUBBER, 0.87 ODX.40THK (KIT OF 10) 2 30913
17-4 BUMPER, RUBBER, 0.63 ODX.31 THK (KIT OF 10) 4 29851
18 KIT, SAFETY BELT BUCKLE w/HDWR 1 22246
19 KIT, SAFETY BELT BUCKLE w/RETRACTOR 1 22245
