FIGURE 5-7: F9T PLATFORM ASSEMBLYSTEPWELL
REF ITEM DESCRIPTION QTY/ASSY PART NO.
1A KIT, ROLLSTOP ASSY, SW, W/HDWR 1 20623
1B KIT, ROLLSTOP ASSY (F9T-SG001 only) 1 20648
2 KIT, PLATFORM GUIDE, RH 1 20649
3 PLATFORM STIFFENER, FRONT 2 20622
4 SAFETREAD, 25.5 X 3, YELLOW 2 25664
5 SAFETREAD, 12.75 X 3.0, YELLOW 1 25673
6 SAFETREAD, 5.5 X 1.5, YELLOW 4 25674
7 SAFETREAD, 25.5 X 12, GRAY 2 25661
8 KIT, STOW GUIDE 2 20625
9 KIT, PLATFORM STIFFENER, REAR 1 20626
10 BEARING, DU, FLNG, ¾ ID X ¼ L, BAG OF 10 1 25386
11A* HANDRAIL ASSY (F9T-SG001 left & right) 1 22530
11B HANDRAIL ASSY, RIGHT HAND (F9T-SG002, F9T-SG004) 1 23066
11C HANDRAIL ASSY, SLOPING, RIGHT HAND (F9T-SG005) 1 F9-0458
12A HANDRAIL ASSY (F9T-SG001 left & right) 1 22530
12B HANDRAIL ASSY, LEFT HAND (F9T-SG002, F9T-SG004) 1 23065
12C HANDRAIL ASSY, SLOPED, LEFT HAND (F9T-SG005) 1 F9-0459
* Handrail styles are continually developing. Contact Ricon Product Support to verify the correct handrail for your ap-
plication.
