FIGURE 5-8: F9T PLATFORM ASSEMBLYLEFT SIDE DETAIL
REF ITEM DESCRIPTION QTY/ASSY PART NO.
1 KIT, MTG BRACKET, LIMIT SWITCH 1 20605
2 KIT, SIDE COVER 1 20606
3 KIT, ACTUATOR FOOT ASSY 1 20607
4A KIT, PLATFORM GUIDE, LH, DE 1 20608
4B KIT, PLATFORM GUIDE, LH, SW 1 20650
5 HARNESS, W/TWO ROLLSTOP SWITCHES 1 UV-ES-221
6 BUMPER, RUBBER, (BAG OF 10) 1 20653
7 KIT, ROLLSTOP RELEASE BRACKET 1 20615
8 SPRING, ROLLSTOP ACTUATOR 1 UV-SP-002
9 SWITCH, LIMIT, W/LEADS 1 264104
10 PLATE, SWITCH, ACTUATOR, PRS 1 UV-PF-918
