16
Connect the Bosch diagnostics tool
Diagnostics cable is placed on the front of the bike to acces it you must
dissasembly the front cover on the bike.
1. Take out the front cover (as show on the picture bellow).
2. Unplug connector protection.
3. Turn on ignition key.
4. Connect Bosch diagnosis tool to the bike and with the computer (use
harness supplement send by Bosch diagnostic tool)
