Motorbike don’t turn ON
Fail: We turn the key but the dashboard doesn’t turn ON, always is black.
Battery doesn’t charge.
Connect diagnosis software to the bike.
a. Any ERROR is show on the software. Check switch-on-relay
b. Diagnosis software can’t connect with the VCU Check fuse of 15A
and check 12V battery.
Check switch-on-relay:
If the relay is NOk when we turn the key to ON position front lights will ON.
To access to the switch on relay, remove the upper plastic cover removing 5
screws.
Take out the relay and apply a voltage of 12V to pins 86 and 85; make sure that
there is continuity between pins 30 and 87.
If the relay is not working, replace it.
If the relay is working, check harness continuity, check fuse of 15A and check
12V battery.
