24
1. Check that the connector is correctly plugged.
2. Check the continuity of the wires.
Fail: We turn the key but the dashboard doesn’t turn ON, always is black.
Battery don’t charge and is impossible connect with the diagnose software.
Check VCU C1 connector:
VCU is placed on the top of the bike to access it you will take out the front
cower removing 2 screws.
1. Check that the connector is correctly plugged
2. Check the continuity of the wires
