41
Fail: Dashboard error light is ON, motorbike doesn’t run. Motorbike charge.
Connect diagnosis software to the bike. If Error 0xAF appears and any throttle
component is affected, check throttle.
Throttle check:
To access to the throttle connector, remove the upper plastic cover removing 5
screws.
1. Check that the connector is correctly plugged
2. Check the continuity of the wires
To Next Page
