Fail: We turn the key the dashboard is ON, but dashboard error light is ON and
motorbike doesn’t run. Motorbike doesn’t charge.
Connect diagnosis software to the bike. If Drive Unit is not connected check
earth cables of the drive unit.
VCU show the following errors:
0x27 : (CAN) Communication fault btw. VCU and EM, Deleted after T15
reset if fault is inactive,
0xAF : (CAN) Communication fault btw. VCU and EM, Deleted after T15
reset if fault is inactive,
0xAE : (CAN) Communication fault btw. VCU and EM, Deleted after T15
reset if fault is inactive,
Check earth cables of the drive Unit:
Power wires are placed up of the electrical motor. Remove the motor cover,
both sides, removing 7 screws.
Checks that the red wires are correctly connected to the engine, check wires
continuity.
