Riello 40 FS - 4 Technical Description of the Burner; Burner Designation; Models Available; Burner Categories - Countries of Destination

7
20063732
GB
Technical description of the burner
4.1 Burner designation
4.2 Models available
Tab. A
4.3 Burner categories - Countries of destination
Tab. B
4 Technical description of the burner
Designation Voltage Code
RIELLO 40 FS10 1/230/50 3756435
Range: RIELLO 40 F
Size
Fuel: Natural gas
Gas oil
LPG
Variations:
Electrical supply of the system: 1/230/50
1/230/60
F S 10 1/230/50
BASIC DESIGNATION
EXTENDED DESIGNATION
1/230V/50Hz
1/230V/60Hz
Light oil - Natural gas
K Conical head
S Reduced ignition output
D Two-stage
R Light oil with pre-heater
S
-
SP
D
Head:
TC Standard head
TL Long head
Country of destination Gas category
SE - FI - AT - GR - DK - ES - GB - IT - IE - PT - IS - CH - NO I
2H
DE I
2ELL
NL I
2L
- I
2E
- I
2
(43,46 ÷ 45,3 MJ/m
3
(0°C))
FR I
2Er
BE I
2E(R)B
LU - PL I
2E
