Maintenance
Gas train
Check that the gas train is suited to the burner capacity, the type
of gas used and the mains gas pressure.
Electrode-probe
Checking the proper positioning of the ionisation probe and elec-
trode as shown in Fig. 10 on page 14.
Pressure switches
Check that the air pressure switch and the gas pressure switch
are set correctly.
Gas leaks
Make sure that there are no gas leaks on the pipe between the
gas meter and the burner.
Gas filter
Change the gas filter when it is dirty.
Combustion
If the combustion values measured before starting maintenance
do not comply with applicable legislation or do not indicate effi-
cient combustion, consult the Tab. F on page 21 or contact our
Technical Support Service to implement the necessary adjust-
ments.
Let the burner run at full power for about 10 minutes, correctly
calibrating all the components indicated in this manual. Then car-
ry out a combustion check verifying:
– Percentage of CO
2
(%)
– CO content (ppm)
– NOx content (ppm)
– Ionisation current (µA)
– Smoke temperature at the flue
Tab. J
7.3 Opening the burner
If maintenance of the combustion head is required, refer to the in-
structions given in “Operating position” on page 13.
For accessing to the interior of the burner, loosen the screws that
secure the cover and proceed with the maintenance operation.
Check the operation
– Start-up of the burner with a sequence of functions (see
chapter “Operation sequence of the burner” on page 23)
– Ignition device
– Air pressure switch
– Flame monitoring
– Tightness test of components to the passage of fuel
Safety component Life cycle
Flame control
10 years or 250,000
operation cycles
Flame sensor
10 years or 250,000
operation cycles
Gas valves (solenoid)
10 years or 250,000
operation cycles
Pressure switches
10 years or 250,000
operation cycles
Pressure adjuster 15 years
Servomotor (electronic
cam) (if present)
10 years or 250,000
operation cycles
Oil valve (solenoid)(if
present)
10 years or 250,000
operation cycles
Oil regulator (if present)
10 years or 250,000
operation cycles
Oil pipes/ couplings
(metallic) (if present)
10 years
Flexible hoses (if present)
5 years or 30,000 pressurised
cycles
Fan impeller 10 years or 500,000 start-ups
Disconnect the electrical supply from the burner
by means of the main system switch.
Turn off the fuel interception tap.
Wait for the components in contact with heat
sources to cool down completely.
Operating safety hazards
Repairs to the following components may only be
carried out by the respective manufacturers or by
personnel instructed by them:
– fan motor
– actuator
– air damper servomotor
– electromagnetic valves
– burner programmer
After carrying out maintenance, cleaning or
checking operations, reassemble the cover and
all the safety and protection devices of the burner.
