20160576
8
Technical description of the burner
4.4 Technical data
Tab. B
(1)
Reference conditions: Ambient temperature 20°C - Gas temperature 15°C - Barometric pressure 1,013 mbar - Altitude 0 m a.s.l.
(2)
Input gas pressure 8)(Fig. 3) with zero pressure in combustion chamber and at maximum burner output.
(3)
Sound pressure measured in manufacturer's combustion laboratory, with burner operating on test boiler, at maximum, average and minimum mod-
ulation output. The sound power is measured with the “Free Field” method, as per EN 15036, and according to an accurate “Accuracy: Category 3”
measurement, as described in EN ISO 3746.
4.5 Electrical data
Tab. C
Model RX 180 S/PV RX 250 S/PV
Type 908T4 903T4
Output
(1)
Delivery
(1)
min - max
min - max
kW
Mcal/h
GAS LPG GAS LPG
30 ÷ 180
26 ÷ 155
36 ÷ 180
31 ÷ 155
42 ÷ 250
36 ÷ 215
50 ÷ 250
43 ÷ 215
Fuel Natural gas: G20 (Natural gas), G25 - LPG: (G31)
Supply pressure
(2)
mbar 15 ÷ 100 (G20)
29 ÷ 100 (G31)
Diameter gas valve inlet 1”
Operation – Intermittent (min. 1 stop in 24 hours).
– Modulating.
Standard applications Boilers: water, steam, diathermic oil
Ambient temperature °C 0 - 50
Combustion air temperature °C max 60
Weight kg 30
Noise level
(3)
Sound pressure
Sound power
dB(A)
39.7
51.6
72.8
84.7
Model RX 180 S/PV RX 250 S/PV
Type 908T4 903T4
Auxiliary circuit electrical supply 1N~ 230V~ +/-10% 50/60 Hz
Electrical supply 1N~ 230V~ +/-10% 50/60 Hz
Fan motor rpm
kW
V
A
5830
0.36
230 V 50/60 Hz
1.6
Ignition transformer V1 - V2
I1 - I2
230 V - 2 x 10 kV
0.3 A - 50/60 Hz - 40 mA
Absorbed electrical power kW max 0.53
Protection level IP40
