Technical description of the burner
4.1 Models available
4.2 Burner categories - Countries of destination
Tab. A
4.3 Burner equipment
Flange for gas train . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
Air intake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
Gas pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
Screws M 5 x 16 for securing the valve . . . . . . . . . . . . . . . No. 4
Insulating screen and gasket . . . . . . . . . . . . . . . . . . . . . . . No. 1
Gas valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
2-pin plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
4-pin plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
7-pin plug. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
Small parts unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
Spare parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
Hardware for burner assembly:
8 x 50 zinc-plated nuts (with or without tip). . . . . . . . . . . . . No. 4
Zinc-plated washers Ø 8. . . . . . . . . . . . . . . . . . . . . . . . . . . No. 4
Zinc-plated toothed washers Ø 8 . . . . . . . . . . . . . . . . . . . . No. 4
M8 Zinc-plated nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 4
4 Technical description of the burner
Designation Voltage Code
RX 180 S/PV 230V - 50-60 Hz 20160021
RX 250 S/PV 230V - 50-60 Hz 20160022
Country of destination Gas category
AT - CH - CZ - ES - FR - GB - GR - HR - IE - IS - IT - LT - PT - RO - SI - SK II2H3P
DE - PL I2E, I3P
NL II2EK3P
HU I2H, I3P
BE I2E(R), I3P
LU I2E
BG - DK - EE - FI - LV - NO - SE I2H
CY - MT I3P
WARNING
The burner is supplied with combustion head and
electrodes assembled.
