Riello MSM 10 - Installation; Preliminary Installation Information

INSTALLATION
ALL THE OPERATIONS DESCRIBED IN THIS SECTION ARE TO BE PERFORMED EXCLUSIVELY BY
QUALIFIED STAFF.
The company declines all liability for damage caused by incorrect connections or operations not described
in this manual.
STORING THE UPS AND THE BATTERY BOX
The storage room must respect the following conditions:
Temperature:
0°÷40°C (32°÷104°F)
Relative humidity:
max. 95%
PREPARING FOR INSTALLATION
PRELIMINARY INFORMATION
UPS models
10 kVA
12 kVA
15 kVA
20 kVA
Rated power
10000 VA
12000 VA
15000 VA
20000 VA
Working temperature
0 ÷ 40 °C
Max. relative humidity during operation
90 % (non-condensing)
Max. height of installation
1000 m at rated power
(-1% Power for every 100 m above 1000 m)
max 4000 m
W x D x H
MCM
320 x 840 x 930 mm
MSM
440 x 850 x 1320 mm
Weight (w/ batteries)
MCM
185 Kg
187 Kg
195 Kg
200 Kg
MSM
315 Kg
320 Kg
325 Kg
330 Kg
Power dissipated at rated resistive load
(pf=0.9) and with battery as buffer *
0.65 kW
560 kcal/h
2218 B.T.U./h
0.76 kW
654 kcal/h
2594 B.T.U./h
0.90 kW
774 kcal/h
3071 B.T.U./h
1.15 kW
989 kcal/h
3924 B.T.U./h
Power dissipated at rated distortion load
(pf=0.7) and with battery charged *
0.50 kW
430 kcal/h
1710 B.T.U./h
0.58 kW
500 kcal/h
1980 B.T.U./h
0.69 kW
594 kcal/h
2355 B.T.U./h
0.90 kW
775 kcal/h
3070 B.T.U./h
Flow rate of fans for removing heat from
installation room **
300 mc/h
355 mc/h
410 mc/h
545 mc/h
Current leak to earth ***
< 7 mA
Isolation protection
IP20
Cable input
From bottom / on rear
* 3.97 B.T.U./h = 1 kcal/h
** The following formula can be used to calculate the fan capacity: Q [mc/h] = 3.1 x P
diss
[kcal/h] / (t
a
- t
e
) [°C]
P
diss
is the dissipated power of all the installed apparatus at the installation premises expressed in kcal/h.
ta= environmental temperature, te= external temperature. To account for leaks, increase the value obtained by 10%.
The table shows an example of the fan capacity with (t
a
- t
e
)=5°C and with nominal resistive load (pf=0.8).
(N.B.: The formula applies if ta>te; otherwise an air conditioner should be installed).
*** The dispersion current of the load is added to the dispersion current of the UPS on the earth protection conductor.
