Riello MSM 10 - View of MCM Connections

VIEW OF THE MCM CONNECTIONS
Connection for the R.E.P.O command (Remote Emergency Power Off)
Slot for power relay board
Connection for remote maintenance bypass command
Connection for external Battery Box temperature probe
Connection for external synchronization signal
Power connections: BATTERY, INPUT, SEPARATE BYPASS (optional), OUTPUT
Area for the single-phase short-circuit bar
