UPS Models
10 kVA
12 kVA
15 kVA
20 kVA
Dimensions and weight
W x D x H
MCM
320 x 840 x 930 mm
MSM
440 x 850 x 1320 mm
Weight without batteries
MCM
80 Kg
82 Kg
90 Kg
95 Kg
MSM
105 Kg
110 Kg
115 Kg
120 Kg
Weight with batteries
MCM
185 Kg
187 Kg
195 Kg
200 Kg
MSM
315 Kg
320 Kg
325 Kg
330 Kg
Modes and efficiency values
Operating modes
True on line double conversion
ECO mode
Smart Active mode
Stand-by Off (Emergency)
Frequency Converter
AC/AC efficiency in on line mode
93.5%
94%
AC/AC efficiency in Eco mode
98%
DC/AC efficiency in autonomy mode
≥92.5%
≥93.5%
Miscellaneous
Noise
≤48dB(A)
≤52dB(A)
Color
RAL 7016
Ambient temperature
(6)
0 – 40 °C
(1)
To maintain the output voltage within the range of precision indicated, it may have to be recalibrated after a long period of operation
(2)
If the mains frequency is within ± 5% of the selected value, the UPS is synchronized with the mains. If the frequency is outside the
tolerance limits or running on the battery, the frequency is the value selected +0.1%
(3)
Mains/Battery @ load 0% -100%
(4)
@ Mains / battery / mains @ resistive load 0% / 100% / 0%
(5)
The recharging current is regulated automatically according to the capacity of the battery installed
(6)
20 – 25 °C for maximum battery life
(7)
@ 100% load & THDv ≤ 1%
Battery Box
BBX 1320 480V
BB NP T4 3F
BBX 1320 480V
BB NP T2 3F
BBX 1320 480V
BB NP T5 3F
Battery
Rated voltage per branch
240 Vdc
No. batteries / V / Ah
80 / 12 / 9
120 / 12 / 7
120 / 12 / 9
Miscellaneous
Ambient temperature
(1)
0 – 40 °C
Humidity
<95% non-condensing
Protective devices
Overcurrent – Short circuit
W x D x H
400 x 815 x 1320 mm
Weight
300 Kg
390 Kg
400 Kg
(1)
20 – 25 °C for maximum battery life
