2. TECHNICAL DATA
2.1 TECHNICAL DATA
TYPE 396T1
Output - Thermal power 10 – 20 kg/h – 118.5 – 237 kW
Fuel Light oil, viscosity 4 –
6 mm
2
/s at 20 °C
Electrical supply
Single phase,
~ 50Hz 220/230 V ± 10%
Single phase,
~ 60Hz 220/230 V ± 10%
Motor
Run current 1.65 A
2775 rpm – 292 rad/s
Run current 2.3 A
302
5 rpm – 318 rad/s
Capacitor 6.3 F
Ignition transformer Secondary 8 kV – 16 mA
Pump Pressure: 8 – 15 bar
Absorbed electrical power 0.37 kW 0.51 kW

2.2 ACCESSORIES (optional):
EXTENDED HEAD KIT
The burner’s combustion head can be replaced by the long-headed version using a special kit, to be ordered
separ
ately.
Refer to the instructions supplie
d with it for installation.
The kit must be installed in conformity with laws and local regulations.
SPACER KIT
There is a special kit available that, when mounted on the burner, lets you reduce head penetration in the
combustion chambe
r.
Refer to the instructions supplied with
the “spacer kit” for installation.
The kit must be installed in conformity with laws and local regulations.
550 SMD CONTROL BOX AND INFRARED FLAME SENSOR
A more efficient control box is available on request, for
teaming with hot air generators, with the following
features:
- spark reset function;
- switch for post-firing and recycle;
- indicator LED reporting various operating stages:
(green LED = motor operating; yellow LED = pre-heating stage; red LED = post-combustion);
- socket for remote reset and reset function in case of faile
d shutdown.
Refer to the instructions supplied with the control box for installation.
The kit must be installed in conformity with laws and local regulations.
REMOTE RESET KIT
There is a special kit available that, when mounted on the 5
50 SMD control box, lets you reset the burner
by remote control.
The kit must be installed in conformity with laws and local regulations.
