COMPONENT CONNECTION TORQUE
Frame Connection between the front and rear frames:
4 M10 screws
30–40 Nm
Fork Steerer tube clamp above the headset (2 screws)
Clamp on steering lever on right side of for tube:
4 M5 screws
Swivel head of the steering lever (M8)
12–14 Nm
5–6 Nm
12–14 Nm
Steering linkage Counter nut M8, swivel head on steering linkage
Front and rear end steering linkage: screw and M6 nut
Universal joint: screw and M8 nuts
9–12 Nm
9–12 Nm
12–14 Nm
Kickstand Counter nuts M8
Eye bolts and M5 nuts for kickstand spring
12–14 Nm
5–6 Nm
COMPONENT CONNECTION TORQUE
Stem Clamping screws M6 (4 pieces)
Front clamping screws M6 (2 pieces)
Rear clamping screws M5 (2 pieces)
Set screws for quick-release for
for angle adjustment (2 pieces)
7–9 Nm
7–9 Nm
3–4 Nm
1 Nm
LOAD: TORQUE SETTINGS
STEM AT KENDU/LOAD: TORQUE SETTINGS
