RECOMMENDED TORQUE SETTINGS
* See the separate enclosed operating instructions of the component manufacturer.
PART FITTING TORQUE
Coaster brake arm Mounting screw 4–6 Nm
Brake lever Mounting screw 5–6 Nm
Shock Mounting screw 7–9 Nm
Freewheel Sprocket cluster lock ring 29–49 Nm
Delite carrier Mounting screw 8–10 Nm
Swingarm bushing Locking screw 5 Nm
Hydraulic brakes Mounting screw
Hydraulic brakes mounting screw
*
*
Crankset Crankbolts
Chainring bolts
35 Nm
8–11 Nm
Hub Quick release lever
Acorn nut for quick release
Axle nut for IGH:
· Shimano hub
· Rohlo hub
· SRAM Dual Drive hub
9–12 Nm
10–25 Nm
30–45 Nm
30–35 Nm
35 Nm
Pedals 35 Nm
Pletscher kickstand Mounting screw M6 12–14 Nm
Rohlo gears
*
Rear light Befestigungsschraube 3–4 Nm
Seat post Mounting screw for seatpost clamp
1/2 bolts
Clamping screw on seatpost
12–15/9–12 Nm
9–12 Nm
Shifter Shimano shifter
Twist grip shifter
4–6 Nm
1–2 Nm
Derailleur Mounting screws
Cable fixing screw
Guide pulley bolts
8–10 Nm
4–6 Nm
3– 4 Nm
Mudguards Mounting screw on frame front / rear 3– 4 Nm
Front derailleur Mounting screw
Cable fixing screw
5–7 Nm
4–6 Nm
V-Brake Mounting screw on frame socket
Cable fixing screw
5–9 Nm
6–8 Nm
A-Headset stem Handlebar clamp 2 / 4 screws
Stem clamp bolt
10 / 5,5 Nm
12–14 Nm
