RIESE & MULLER load - Suspension Seat Post (blueLABEL)

33
The stiness of the seat post can be ad-
justed (within certain limits) to the weight of
the rider.
• Open the seat post clamp on the frame and
remove the seat post from the frame.
• Adjust the spring preload with a 6 mm Allen
key. Turn clockwise to increase the tension.
Rotate counter-clockwise to decrease the
preload. The preload can only be reduced to
the extent that the adjustment screw
D doesn’t project out of the seat post.
• Install the seat post in the frame
(see page 21 ).
If the lateral play between shaft and outer
tube is too great you can rotate the nut E by
hand to make it a bit harder. Make sure that
the boot does not slip o of the nut. Do a
regular check if the nut E has a tight fit
SUSPENSION SEAT POST (ONLY FOR blueLABEL)
D
E
