Document Overview
This manual gives you a quick overview of the front and rear panel, user interface as
well as basic operation methods of DHO800 series.
TIP
For the latest version of this manual, download it from RIGOL official website
Publication Number
QGA36101-1110
Software Version
Software upgrade might change or add product features. Please acquire the latest
version of the manual
Format Conventions in this Manual
1. Key
The front panel key is denoted by the menu key icon. For example,
indicates the "Default" key.
2. Menu
The menu it
em is denoted by the format of "Menu Name (Bold) + Character
Shading" in the manual. For example,
Setup indicates the "Setup" sub-menu under
the "Utility
" function menu. You can click or tap
Setup to access the "Setup" menu.
3.
Operation Procedures
The next step of the operation is denoted by ">" in the manual. For example,
> Storage indicates fir
st clicking or tapping
and then clicking or tapping
Storage.
4. Connect
or
The front/rear panel connector is denoted by "Brackets + Connector Name (Bold)",
for example, [AUX OUT].
Content Conventions in this Manual
DHO800 series digital oscilloscope includes the following models. Four-channel
models and two-channel models share the same operation method. Unless otherwise
specified, this manual takes the four-channel model DHO814 as an example to
illustrate the operation methods of DHO800 series oscilloscope.
Document Overview
6
