RIGOL
©
2007 RIGOL T
echnologies, Inc.
User‟s Guide f
or DM3000 Series
2-
51
1.
Data Log rate
T
o set the Data Log sample rate.
Press
Log
Sa/s, the interface shows below
.
Figure 2-
60
The Data L
og
Rate Setting Interface
T
able 2-
37
The Data Log Rate Setting Menu Description
Function
Menu
S
etting
Description
1/10m
1/5m
.
.
50k/s
T
o
set
the
sample
rate with
13
values
from
1/10m to 50k/s.
Save
all
the
changes,
back
to
a
higher
level
menu.
The system has 13 Data Log rates.
100
102
