Chapter 4 Prompt Messages& Troubleshooting
Prompting Message
1． Delay time is 400 to 2000ms
In trigger setting, the setting value scope of auto trigger delay time is
400~2000ms.
2． No useful Math
Currently measurement function is not available for Math function.
3． The range of the short resistance is 1Ω to 2000Ω
In continuity measurement, the short-current resistance setting value scope is
1Ω~2000Ω.
4． Sample is 1 to 50,000
Single trigger sampling number scope is 1~ 50,000.
5． Achieves the Maximum number
In sensor setting, the reference value number gets the max value.
6． Number of reference value is **
The sensor reference value number is: **.
7． Resistance is -120MΩ to +120MΩ
In limit test and null value settings the resistance value scope: -120MΩ~120MΩ.
8． The periods setting value must larger than 1μs
In limit test and null value settings the periods setting value should be bigger
than 1μs.
9． Value is unable
Null value function setting value cannot surpass the measuring range scope.
10. Upper limit should larger than lower limit
In limit measurement the Upper limit should larger than lower limit.
11. GPIB address is from 0 to 31
GPIB I/O interface address setting value scope: 0 ~ 31.
