To Choose Reading Resolution
The measurement reading resolutions (the accuracy) are 4 1/2, 5 1/2, 6 1/2 digits.
Figure 1- 57 The Digits Resolution Control Keys
Methods:
Use the left and/or right direction key to adjust the desired measurement resolution.
Press left button to decrease accuracy, press right button to increase accuracy.
The digits resolving index Selection
(1). Each precision of the measure function can be set separately without influence.
(2). Choose the reading precision of 6 1/2 bit when measuring AC for best results.
(3). Save the digits resolving index in volatile memory.
Increases the index
Reduce the index
